Doughty Hanging Truss Adapter

Doughty Hanging Truss Adapter

The Doughty Hanging Truss Adapter enables triangular and square truss sections to be mounted to any of the Doughty Winch Stand range. This system provides the means to lift truss sections into place safely.

The range of Hanging Truss Adapters is supplied with a Hanging Ring and two Slimline Half Couplers. Designed to suspend truss sections with a chain hoist. Two sizes available.

Heavy-Duty-Adapters are also available. For any inquiries, please contact us via chat.

Downloads:

User Manual

Key Features:

• Provides a safe and secure means of lifting trusses
• Adjustable to suit most truss sizes
• Comes with two high tensile 6082-T6 aluminum couplers
• High-quality silver powder coated
• Compatible with triangular and square truss sections

Specifications:

• SWL: 441 lbs
• Tube diameter: 1.9'' - 2''
• Truss Adapter Size: 7.9'' - 15.7'' Centers
• Width: 3''
• Includes Hanging Ring and two Slimline Half Couplers

References:

• Manufactured by Doughty Engineering
• Member of ESTA and PLASA
• Established in 1985 in the UK

Doughty Engineering is a UK-based entertainment equipment manufacturer and began the manufacture of products in 1985. Now, it is one of the world’s leading manufacturers of rigging, suspension and lifting equipment for film/TV, theatre and concert halls. Quality and safety are key issues for Doughty. As a member of ESTA (Entertainment Services and Technology Association) and PLASA (Professional Light and Sound Association), it adheres strictly to the standards of trading expected.
