Badger Manual Hoist 0.5t to 10t

Badger Manual Hoist 0.5t to 10t

The Badger Manual Hoist (0.5t to 10t) is a low headroom, lightweight, and durable hoist that is designed for lifting and pulling operations in various settings. It features a formed steel enclosure that protects against contamination, fully enclosed gearing, a self-adjusting load brake, and drop forged alloy hooks with heavy-duty safety latches, among other features.

• Low Headroom and Lightweight Enclosure: Our revolutionary low headroom hoist that boasts impressive features to make your lifting and pulling jobs a breeze. Our hoist is designed with a light-weight and durable formed steel enclosure that protects against contamination and can be quickly disassembled for easy maintenance. The powder coating and plated finishes on exposed components resist corrosion, keeping the hoist in service longer.
• Hand Chain Opening with Radius: The hand chain opening is uniquely formed with a radius, allowing for operation from the side or even above, making it easy to lift or pull objects.
• Heat Treated Internal Parts and Enclosed Gearing: The internal parts of the hoist are heat-treated for strength and reliability and feature fully enclosed gearing to protect against contamination. All gears and shafts run on caged roller bearings, ensuring smooth operation and long life.
• Self-Adjusting Weston Style Load Brake: Our hoist also features a Weston style mechanical load brake that is self-adjusting with double pawls and asbestos-free brake discs, all of which are enclosed to limit contamination.
• Drop Forged Alloy Hooks with Safety Latch: The drop-forged alloy hooks are designed to stretch when overloaded before chain failure, and they come equipped with heavy-duty cast steel safety latches attached by a bolt and lock nut. The top hook mounting articulates to aid in rigging and ensure straight line loading between hooks.
• Grade 80 Zinc Plated Alloy Load Chain and Proof Tested: Our hoist comes with a grade 80 zinc-plated alloy load chain and is proof-tested to a minimum of 1.25 times the weight load limit (WLL).
• Certified with Spare Parts and Manual: Each hoist is shipped with a certification of test matching the individualized serial number stamped in the nameplate. An operation and spare parts manual is also supplied in English, French, and Spanish.
• Compliant with Safety Standards: The hoist meets ASME B30.16, OSHA, and NASA-STD-8719.9 safety standards, ensuring your safety during use. It is available in lifts of 10, 20, and 30 feet. Unchained units and bulk chain are available for customers to make their own custom lifts if assembled and tested per ASME B30,16 before being placed into service.
• Optional Overload Protection: Additionally, we offer an optional overload protection set at approximately 175% WLL, giving you extra peace of mind during use.

Order our Badger Manual Hoist (0.5t to 10t) today and experience the benefits of a durable, reliable, and high-quality hoist that is designed to make your lifting and pulling jobs safer and easier.

Badger Manual Hoist 0.5t to 10t Specifications:

• Brand: All Material Handling (AMH)
• Series: Badger CB Series
• Chain: Grade 80 Zinc Plated Alloy Load Chain
