AMH Beam Clamp 1t to 10t

AMH Beam Clamp 1t - 10t

The AMH Beam Clamp offers a variety of benefits to users, such as strong and reliable support for materials up to 10 tons. It is highly durable and corrosion-resistant, making it ideal for use in different environments.

Additionally, the clamp is easy to install and requires minimal maintenance. It also offers easy access for inspection and repairs, ensuring that your operations run smoothly.

• Our 5:1 design factor hoist mount and rigging point makes installation easy and straightforward (powered or manual hoists).
• It requires no tools, has a low headroom design, and is portable – perfect for any setup.
• Choose from the BCD model, which has a movable shackle, or the BC model.
• Both have a matte black color that meets OSHA, ASME B30, NASA-STD-8719.9 and EU Directives: 2006/42/EC, for a professional look that is perfect for theater applications and other venues.

AMH Beam Clamp Specification:

• Type: Pin/Bar
• Color: Matte Black
• 1 Ton
• MPN: BC-01
• Working Load Limit (tons): 1
• Working Load Limit (lbs): 2,200
• Safety Factor: 5:1
• Beam Size: 3.1" - 9.4" x 0.75"
• Approx. Weight (lbs): 7.7
• 2 Tons
• MPN: BC-02
• Working Load Limit (tons): 2
• Working Load Limit (lbs): 4,400
• Safety Factor: 5:1
• Beam Size: 3.1" - 9.4" x 0.75"
• Approx. Weight (lbs): 9.9
• 3 Tons
• MPN: BC-03
• Working Load Limit (tons): 3
• Working Load Limit (lbs): 6,600
• Safety Factor: 5:1
• Beam Size: 3.5" - 12.2" x 1.12"
• Approx. Weight (lbs): 20.9
• 5 Tons
• MPN: BC-05
• Working Load Limit (tons): 5
• Working Load Limit (lbs): 11,000
• Safety Factor: 5:1
• Beam Size: 3.5" - 12.2" x 1.41"
• Approx. Weight (lbs): 24.2
• 10 Tons
• MPN: BC-10
• Working Load Limit (tons): 10
• Working Load Limit (lbs): 22,000
• Safety Factor: 5:1
• Beam Size: 3.5" - 12.6" x 1.50"
• Approx. Weight (lbs): 35
