Harrington Hoist: CF Hand Chain Hoist 0.5-5 Ton

• DESCRIPTION
• SPECIFICATIONS
• FEATURES
• RESOURCES

CF Harrington Hoist 0.5-5 Ton

As a highly recommended chain hoist brand, Harrington's CF hand chain hoists were designed for portability and durability. These Harrington hoists are the economical and practical choice for efficient, trouble-free service. The CF model is a long-lasting construction grade hoist that offers the best value in a hand chain hoist.

• Experience exceptional strength with a thick die-cast aluminum body
• Handle tough demands with high-strength, heat-treated main pinion shaft and load gear
• Get positive braking action with Weston-style load brake incorporating two moisture-resistant brake pads with four braking surfaces
• Minimize manual effort thanks to smooth running, pre-lubricated ball bearings, and precision machined drive train components
• Simplify maintenance with fewer parts and an easy-to-work-on design
• Forged and heat-treated alloy steel hooks are designed to open slowly and not fracture under excessive loads

• Capacities: 1/2 Ton - 5 Ton
• 10-foot lift is standard, 15- and 20-foot lifts are also stocked; nonstandard lifts and hand chain drops available as well.
• Grade 100 heat-treated manganese alloy load chain resists abrasion and wear while minimizing chain weight
• Test certificate verifies that every hoist has been factory load tested to 125% of rated capacity, in accordance with ASME B30.16 requirements.
• Covered by a two-year warranty from date of shipment against defects in workmanship or materials
