Vestil Manufacturing Corp Pallet Master/Servers
Product No. PMPS-50-AIR
Shipping calculator
Payment methods
Product details
Vestil Manufacturing Corp Pallet Master/Servers
*Non Cancelable/Returnable*
The Pallet Master/Servers, are designed to be used when a fork truck is not available. The Pallet Master/Servers can handle pallets and skids both with and without an understructure. Capacity rated is at 18" regardless of fork length. The forks are 36" long for handling a wide variety of pallet sizes. Move the unit around easily on 8" x 3" (8" x 2" locking standard on LL-PMPS) phenolic swivel rear casters Floor lock standard on PMPS series. Handle height is 36". Outriggers are adjustable on series LL-PMPS, inside straddle width is adjustable between 34" to 50-1/2".
PTDS-E -- Power Traction Drive option reduce worker fatigue and injury. An alternative to costly fork trucks, the PTDS-E includes combination throttle / direction controller and auto reverse emergency "belly" switch. This state of the art option allows a single operator to safely and easily move products. Maximum speed is 2.5 m.p.h. 24V DC system.
Three Power Options to choose from:
- Suffix-AC is 115V 1 phase power with a push-button hand control
- Suffix-DC includes one (1) 12V battery, push-button hand control, an on-board charger and battery charege indicator gauge.
- Suffix-AIR feautres reciprocating air/oil power with a heel/toe foot treadle control/
Manuals
PMPSOwners Manual
LL-PMPSOwners Manual
AUTOSHIFTEROwners Manual
Testing Certificates
SDS Sheets
Hydraulic Oil SDS Sheet for: PMPS-50-AIR
*For Vestil products, a minimum purchase amount of $25 is required to place an order.*
