SMC Advance Tech Mate Double Pulley – NFPA

The SMC Advance Tech Mate Double Pulley is an NFPA compliant double pulley designed to work with the Advance Tech HX Pulley in a mini haul system. The pulley frame is perfect for use in a compact haul kit. Integrated stainless steel pins retain the rope when a rigged system is pre-packed for quick setup.

Features

• High quality aluminum construction
• Anodized to help prevent corrosion
• Supports 7mm – 12.5mm rope
• Stainless steel retaining pins
• NFPA 1983 (2012), T
• Berry Compliant
• Made in the USA

Specs

• Color: Orange/Grey
• Type: Double Pulley
• MBS: 34 kN (7644 lbf)
• Weight: 5.4 oz (154 g)
• Length: 2.97" (7.5 cm)
• Width: 2.40" (6.1 cm)
• Height: 1.81" (4.6 cm)
• Axle: Ball Bearing
• Sheave: 1.37" Aluminum
• Tread: 1.00"
• Max Rope Size: 12.5 mm
• Material: Anodized Aluminum
