Maxx-Parts Tilter
The Maxx-Parts Tilters are designed to transport, tilt, dump, and dispense parts. The manual pump tilt is an economical solution to dispensing parts throughout a location with a chute lock in place to secure the load while in motion. Dual handles are used to tilt the bin and allow the operator to tilt without having to move around the unit. A centrally located manual release valve is used to efficiently lower the bin. With a tilt range of 0-40° and capacity of 2,000-3,500 lbs. the Maxx-Parts Tilter Series can handle most transporting, dispensing, and parts sorting applications.
The base model has a chute length of 16" and can be customized per requirement as well as the bin size. Fork pockets are standard on all models allowing the Maxx-Parts Tilter to be easily moved around a facility to dispense parts at required locations by use of a walk behind stacker or fork truck. Optionally, the unit can be mounted to the top of various types of lift carts.
Standard Features
-
Tilt Range: 0° - 40°
-
Tilt Adjustment 1° per pump
-
Dual Pump Levers for easy adjustment
-
U.S. Patent number 4720232
-
Manual Lowering control valve
-
Chute locks
-
Fork Pockets
-
Units are stackable to save space
Options
- Stacker
- Cart Mounted
- Custom Bin Sizes
- Custom Chutes
Specifications
| Model | Capacity | Tilt | Bin | Overall | Chute Length |
|||||
|---|---|---|---|---|---|---|---|---|---|---|
| W | L | H | ft³ | W | L | H | ||||
| LPPH-30-12 | 2,000 | 0-40° | 24" | 30" | 12" | 5 | 26" | 40" | 19.2" | 16" |
| LPPH-36-12 | 3,000 | 0-40° | 24" | 36" | 12" | 6 | 26" | 46" | 19.2" | 16" |
| LPPH-36-16 | 3,000 | 0-40° | 24" | 36" | 16" | 8 | 26" | 46" | 23.2" | 16" |
| LPPH-40-16 | 3,500 | 0-40° | 28" | 40" | 16" | 10.3 | 30" | 50" | 23.2" | 16" |
