3M™ DBI-SALA® D-ring with Anchorage Plate

The 3M™ DBI-SALA® D-ring with Anchorage Plate is a critical component in most fall protection systems as it securely attaches your system to the anchorage. This compact stainless steel plate, through 1/2'' pre-drilled holes, can either be bolted or welded to a structure in order to provide a fall arrest anchor point. With a high strength steel construction, this anchorage plate also includes a zinc plated steel / 304 stainless steel / 316 stainless steel D-ring for compatible tie-off point. The 3M™ DBI-SALA® D-ring with Anchorage Plate is built from top quality, rugged and corrosion resistant materials that guarantee high strength and durability to stand up to the toughest of environments.

For any inquiries please contact us via Chat.

SPECIFICATIONS

• Capacity: 310 lbs (141 kg) ANSI / 420 lbs (190 kg) OSHA
• Weight: 1.2 lbs
• Dimensions: 1/4" x 2" x 4.5"
• Attachment Type: Bolt / Weld
• Plate Material:
  2101630 - 304 Stainless Steel
  2101634 - Raw Steel
  2101636 - 304 Stainless Steel
  2101638 - 316 Stainless Steel
• D-ring Material:
  2101630 - Zinc Plated Steel
  2101634 - Zinc Plated Steel
  2101636 - 304 Stainless Steel
  2101638 - 316 Stainless Steel
• Color: Silver, Yellow Zinc
• Install Type: Permanent
• iSafe Equipped: No
• Recommended Industry: Construction, General Industrial, Mining, Oil & Gas, Transportation, Utilities, Wind Energy
• Standards: ANSI Z359.1, OSHA 1910.66, OSHA 1926.502

FEATURES

• Bolt or weld to structure for fall arrest anchor point
• Compact 1/4" x 2" x 4.5" steel plate
• Pre-drilled 1/2'' holes
• 2101630: 304 stainless steel plate with zinc plated steel D-ring for compatible tie-off point
• 2101634: Raw steel plate with zinc plated steel D-ring for compatible tie-off point
• 2101636: 304 stainless steel plate with 304 stainless steel D-ring for compatible tie-off point
• 2101638: 316 stainless steel plate with 316 stainless steel D-ring for compatible tie-off point
• High strength steel construction
• Extremely rugged and corrosion resistant
