Adaptive Technologies Group MultiMount MM-060-Z Outdoor pan & tilt speaker mount

Adaptive Technologies Group MultiMount MM-060-Z Outdoor Pan and Tilt Speaker Mount

The Adaptive Technologies Group MM-060-Z attaches to the back or bottom panel of weatherized loudspeakers and aims them from walls and other vertical structures. It gives up to 180 degrees of pan and 45 degrees of no-drift, screw-drive tilt.

It is rated 84 lb (38.1 kg) at a 5:1 design factor and has a silver finish for outdoor use.

Key Features and Highlights

• 84 lb (38.1 kg) WLL: 5:1 design factor.
• Pan 180, tilt 45 degrees: Screw-drive tilt, clutch-style pan lock.
• Outdoor version: Silver powder coat for weatherized speakers.
• Mounting patterns: 2-3/4 x 5 in and 2 x 4-1/4 in.
• Extension arm option: MM-060-8ARM 8 in extension.

Who Is This Product For?

Ideal for: Installers mounting weatherized loudspeakers outdoors.

Important: Always install safety cables.

Specifications

• Part Number: MM-060-Z
• WLL (Working Load Limit): 84 lb (38.1 kg) max
• Design Factor: 5:1
• Pan: Up to 180 degrees
• Tilt: Up to 45 degrees
• Mounting Patterns: 2-3/4 x 5 in, 2 x 4-1/4 in
• Material: Structural steel, powder coat
