Doughty Heavy Duty Awning Brackets

Doughty Heavy Duty Awning Brackets

A Pair of Heavy Duty Awning Brackets designed for robust rigging applications. Engineered to work seamlessly with M12 shackles and compatible with a range of pulley configurations.

Available in Single, Double, and Triple-Sheave versions to suit a wide variety of lifting and rigging requirements. For optimal performance, please specify the exact components when placing your order.

To order pulleys, please state part numbers of: 1. Basic Pulley required 2. Fixing System required. For example: T42901 + T42984 = 100mm Single Pulley (for wire) fitted with Awning Brackets. For any inquiries, please contact us via chat.

Downloads:

User Manual

Key Features:

• Supplied as a pair for balanced load distribution
• Compatible with M12 shackles for secure installations
• Available in Single, Double, and Triple-Sheave configurations
• Customizable with various pulley and fixing combinations
• Durable construction for heavy duty applications

Specifications:

• T42984/T42985/T42986: For ⌀100mm & 150mm sheaves, SWL: 400kg
• T42987/T42988/T42989: For ⌀200mm sheaves, SWL: 600kg
• Ø100mm = 12mm Rope / 4mm Wire
• Ø150mm = 18mm Rope / 6mm Wire
• Ø200mm = 18mm Rope / 6mm Wire

References:

• Part Number Example: T42901 + T42984 = 100mm Single Pulley (for wire) fitted with Awning Brackets
• Fixing Systems: T42984, T42985, T42986, T42987, T42988, T42989
• Please contact us via chat for ordering assistance or technical support

Enhance your rigging setup with Doughty's reliable and heavy-duty awning bracket solutions, designed for strength, compatibility, and ease of installation.
