DOUGHTY HALF COUPLER

The Doughty Half Coupler is the basis of the range of Doughty Clamps.

This robust Half Coupler has a slotted base to fit an M12 Nut or Bolt, enabling users to create fixings suited to their own individual requirements.

The Doughty Half Coupler combines strength and durability with a high degree of safety.
It is designed to attach to 2'' diameter round tubes or truss chords and suspend equipment and luminaries in the entertainment industries, e.g. film/TV, theatre and concert halls.

Due to the increasing number of outdoor events using truss roof systems etc, we supply the Half Coupler with stainless steel fasteners. This truss clamp is ideally used outdoors for prolonged periods while minimizing any galvanic corrosion.

Half Coupler Demonstration - A Light Quickly Hung Onto a Truss

For any inquiries, please contact us via chat.

 SPECIFICATIONS

• TÜV Certified
• SWL: 1650 lbs
• Tube Diameters: fits 2" diameter tubes
• Width: 1.97"
• Fixings: M12 Hole
• Weight: 1.39 lbs
• Material: High tensile 6082-T6 aluminium
• Finish: Black or Polished Aluminium

Doughty Half Coupler Infographic

Doughty Engineering is a UK-based entertainment equipment manufacturer and began the manufacture of products in 1985. Now, it is one of the world’s leading manufacturers of rigging, suspension and lifting equipment for film/TV, theatre and concert halls.

Quality and safety are key issues for Doughty. All our products are subjected to the most rigorous testing possible and, where appropriate, are approved by the TÜV product services. Such products show the TÜV logo.

Doughty® are members of ESTA (Entertainment Services and Technology Association) and PLASA (Professional Light and Sound Association) and adhere strictly to the standards of trading expected
