Lex Crossover 45 Degree Right Turn Unit
Product No. PRTR-5
Protects cables and hoses from damage when run across roads, parking lots, sidewalks and pathways, providing safe crossing for pedestrian and vehicle traffic.
- Length: 25"
- Width: 19.75"
- Height: 2"
- Weight: 15.5lbs.
- Slot Height: (5) 1.25" Channels
- Slot Width: (4) 1.25" Channels / (1) 1.625" Center Channel
- Material: Base & Lid: Polyurethane / Hinge Pin: Reinforced Fiberglass
- Load Capacity Per Tire/Axle: 16ZZ300 lbs. Per Tire / 32,000 lbs. Per Axle at 70ºF
- Safety Warning Symbols: Per ANSI Z535.3-2011-Molded in Lid
- Operating Temperature: -40ºF to 120ºF / -40ºC to 48ºC
- Heavy-duty, non-conductive polyrethane constructon provides safe crossing for pedestrians and vehicles while protecting electrical cables and hose lines
- Rugged industry standard connectors with exclusive "slip notch" fritction release design provides easy mating and un-mating
- Mates with major cable protector brands and products
- 5-channel design can accomodate up to 1.25 inch diameter cables and hoses
- 1.625 inch wide center channel allows for up to #2 AWG 5-wire banded sets
- Exclusive tread design provides excellent traction
- Hinged lid provides easy access for insertion and removal of cables and hoses
- Made from UV stabilized material for prolonged use in direct sunlight
- High-visibility blue lid and black base
